Material:	Low Carbon Steel / 300 Series Stainless Steel	Type:	Welded Bar Grating
Anti-corrosion:	H.D Galvanized / PVDF / Powder	Dimension:	Custom-made

Hot Dipped Galvanized Steel Bar Grating | 80micron Zn Coating| 100X10mm load bar, HESLY Factory sales China Supplier

Steel Bar Grating is able to support heavier loads than plank grating, bar grating is good for trenches, mezzanines, walkways, work platforms, and floors. This grating has an open design that allows air, light, and debris to flow through. Cross bars hold the bearing bars in place; bearing bars help distribute weight and must rest on supports. Use Fasteners for Metal Bar Grating to secure.

Serrated grating provides maximum slip resistance.

Powder-coated steel grating is for use in dry, noncorrosive areas.

Galvanized steel grating is more corrosion resistant than powder-coated steel.

Stainless steel grating has better corrosion resistance than steel or aluminum.

Type of Bearing Bars

Specify the type of grating required by reference of our four main types of products: Plain steel grating, serrated steel grating, I bar steel grating.


Plain Bearing Bar	Serrated Bearing Bar	"I" Type Bearing Bar	"I" serrated Bearing Bar

Carbon Steel Finish Options

Bare Steel

Mill finished carbon steel bars

without additional coating. Will

show discolorationfrom welding

and fabrication. Subject to rusting.

Hot Dip Galvanized

Zinc coating applied in accordance

with ASTM A123. Provides long

lasting corrosion resistance.

Powder Coating

One coat of HeslyGratings'

standard coating. Stand colors are

green,

black, red, and blue etc.

Other Finishes: PVDF etc

Specialty coatings may be specified

in a wide range of colors.
Some options include PVDF,

painting, or epoxy paints.

Load Capacity of Heavy Duty Steel Grating

Important !
The charge-capacity at the grating is determined by the height and thickness of the bearing-bars (=supporting-bars). The bearing-bar must always be supported. Therefore, the bearing-bar is in all our documents = first dimension. Cross-bars and bordering off the grid contribute to the stability.

Common Specifications Sheet - HESLY Steel Grating

Series	Pitch of Bearing bar	Cross-bar Pitch	Specification of bearing bar load width×thickness
Series	Pitch of Bearing bar	Cross-bar Pitch	20×3	25×3	32×3	40×3	20×5	25×5
1	30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
1	30	50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
2	40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
2	40	50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
3	60	50		G253/60/50	G253/60/50	G403/60/50	G205/60/50	G255/60/50
Series	Pitch of Bearing bar	Cross-bar Pitch	Specification of bearing bar load width×thickness
Series	Pitch of Bearing bar	Cross-bar Pitch	32×5	40×5	45×5	50×5	55×5	60×5
1	30	100	G325/30/100	G405/30/100	G455/30/100	G505/30/100	G555/30/100	G605/30/100
1	30	50	G325/30/50	G405/30/50	G455/30/50	G505/30/50	G555/30/50	G605/30/50
2	40	100	G325/40/100	G405/40/100	G455/40/100	G505/40/100	G555/40/100	G605/40/100
2	40	50	G325/40/50	G405/40/50	G455/40/50	G505/40/50	G555/40/50	G605/40/50
3	60	50	G325/60/50	G405/60/50	G455/60/50	G505/60/50	G555/60/50	G605/60/50

Reference Photos - HESLY Steel Bar Grating


Forge Welded Bar Grating Factory	Serrated Bar Grating Supplier	Press Locked Grating

**Steel Clips for Steel Grating**

Steel Grating Clips	Steel Bar Grating Clips	Steel Grating Clips

Package and Delivery


Hot Dipped Galvanised Bar Grating	Welded Bar Grating Exporter	Container Loading

How to Order Hesly Steel Bar Grating Products ?

To Order

For custom sizes, please specify width and length. Note: Grating less than 17" long is reinforced with banding.

The Hesly Steel grating is available in various material, such as Mild Carbon Steel, Stainless steel and Aluminum alloy. Among them, Mild carbon steel grating is the most cost effective and economical type, and hot dipped galvanized surface treatment supplies excellent corrosion resistance performance for durability. And it is the most widely used in both industrial, commercial and residential applications.

Required Information for a formal quotation

Material: Mild Carbon, 304/316 stainless steel, Aluminium
Dimension: Width X Span (length of the bearing bar)
Bearing Type: Flat or Serrated
Bearing Bar (Depth X Thickness)
Spacing of the bearing bars
Cross Bar Diameter & style (squre twisted or round bar)
Cross Bar Pitch
With End bands or Not
Finish: galvanized, powder or PVDF
QUANTITY (very important for the cost)
If need C.F.R offer, just let us the Destination Sea Port.

Contact us for a FREE prompt quotation !
