Place of Origin: | EON-HESLY METAL MESH, Anping China |
---|---|
Brand Name: | HESLY/海斯利 |
Certification: | ISO9001:2008 |
Model Number: | G325/40/50 |
Minimum Order Quantity: | 10 m2 |
Price: | negotiated as per the order |
Packaging Details: | In bulk |
Delivery Time: | According to the order |
Payment Terms: | T/T, L/C |
Supply Ability: | 8days/20'GP |
Wire Diameter: | 5mm | Material: | Galvanized Steel Wire |
---|---|---|---|
Type: | Welded Mesh | Application: | Protecting Mesh |
Weave Style: | Plain Weave | Technique: | Welded Mesh |
Welded Steel Bar Grating is the workhorse of the industrial flooring market and has served industry for decades.Strong and durable with an exceptional strength-to-weight ratio, metal bar grating can be easily fabricated to nearly any configuration.The high percentage of open area makes bar grating practically maintenance-free and all products are fully recyclable.
Manufactured by assembling a series of equally spaced metal bars to connecting cross members, bar grating is available in three popular materials; mild carbon steel, 6000 series aluminum, and 300 series stainless steels.
A).Type of Grating
Plain Bearing Bar | Serrated Bearing Bar | "I" Type Bearing Bar | "I" serrated Bearing Bar |
Bearing bar centers at 40mm:
This is our project of steel grating ,it can be used to many aspects just like: | ||||
platform | trestle | trend | fence | equipment walk way |
pavement | channel over | manhole cover | trash rack | mentance platform |
foot bridge | scaffold | ladder | storage shelf | marine platform |
Bearing Bar Spacing | Cross Bar Spacing |
Bearing Bar Specification ( Width * Thickness)
|
|||||||
( mm ) |
( mm ) |
32*5 ( mm ) |
40*5 ( mm ) |
45*5 ( mm ) |
50*5 ( mm ) |
55*5 ( mm ) |
60*5 ( mm ) |
||
30 |
100 |
G325/30/100 |
G405/30/100 |
G455/30/100 |
G505/30/100 |
G555/30/100 |
G605/30/100 |
||
|
50
|
G325/30/50 |
G405/30/50 |
G4555/30/50 |
G505/30/50 |
G555/30/50 |
G605/30/50 |
||
40 |
100 |
G325/40/100 |
G405/40/100 |
G455/40/100 |
G505/40/100 |
G555/40/100 |
G605/40/100 |
||
|
50
|
G325/40/50 |
G405/40/50 |
G455/40/50 |
G505/40/50 |
G555/40/50 |
G605/40/50 |
||
60 |
50 |
G325/60/50 |
G405/60/50 |
G455/60/50 |
G505/60/50 |
G555/60/50 |
G605/60/50 |
material
