HeslyGratingn-China manufactures a wide variety of steel bar grating including standard, heavy duty and customized shapes and sizes with various finishes making our products suitable for all kinds of applications. Stock products can be supplied quickly from strategically located sales and warehouse facilities. Also, custom grating jobs can be manufactured to very particular requirements by our personnel in either Imperial or Metric measurements.

Our grating products are routinely used in the mining, petroleum, petrochemical, pulp & paper, water treatment, chemical, and power generation industries. They also are used extensively in the transportation industry, including railroad, airport and transport truck, and in the military.

The Hesly Steel grating is available in various material, such as Mild Carbon Steel, Stainless steel and Aluminum alloy. Among them, Mild carbon steel grating is the most cost effective and  economical type, and hot dipped galvanized surface treatment supplies excellent corrosion resistance performance for durability. And it is the most widely used in both industrial, commercial and residential applications.

Type of Bearing Bars

Plain Bearing Bar	Serrated Bearing Bar	"I" Type Bearing Bar	"I" serrated Bearing Bar

Carbon Steel Finish Options

Bare Steel Mill finished carbon steel bars without additional coating. Will show discolorationfrom welding and fabrication. Subject to rusting.	Hot Dip Galvanized Zinc coating applied in accordance with ASTM A123. Provides long lasting corrosion resistance.	Powder Coating One coat of HeslyGratings' standard coating. Stand colors are green, black, red, and blue etc.	Other Finishes: PVDF etc Specialty coatings may be specified in a wide range of colors. Some options include PVDF, painting, or epoxy paints.

Load Capacity of Heavy Duty Steel Grating

Important ! The charge-capacity at the grating is determined by the height and thickness of the bearing-bars (=supporting-bars). The bearing-bar must always be supported. Therefore, the bearing-bar is in all our documents = first dimension. Cross-bars and bordering off the grid contribute to the stability.



Common Specifications Sheet - HESLY Steel Grating

Series	Pitch of Bearing bar	Cross-bar Pitch	Specification of bearing bar load width×thickness
			20×3	25×3	32×3	40×3	20×5	25×5
1	30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
		50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
2	40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
		50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
3	60	50		G253/60/50	G253/60/50	G403/60/50	G205/60/50	G255/60/50
Series	Pitch of Bearing bar	Cross-bar Pitch	Specification of bearing bar load width×thickness
			32×5	40×5	45×5	50×5	55×5	60×5
1	30	100	G325/30/100	G405/30/100	G455/30/100	G505/30/100	G555/30/100	G605/30/100
		50	G325/30/50	G405/30/50	G455/30/50	G505/30/50	G555/30/50	G605/30/50
2	40	100	G325/40/100	G405/40/100	G455/40/100	G505/40/100	G555/40/100	G605/40/100
		50	G325/40/50	G405/40/50	G455/40/50	G505/40/50	G555/40/50	G605/40/50
3	60	50	G325/60/50	G405/60/50	G455/60/50	G505/60/50	G555/60/50	G605/60/50

Reference Photos - HESLY Steel Bar Grating

Welded Bar Grating Factory	Welded Bar Grating Supplier	China Galvanized Grating



Steel Clips for Steel Grating

Steel Grating Clips	Steel Bar Grating Clips	Steel Grating Clips

Package and Delivery

Hot Dipped Galvanised Bar Grating	Welded Bar Grating Exporter	Container Loading



How to Order Hesly Steel Bar Grating Products ?

Just let us know below the information marked on the drawing.


Required Information for a formal quotation   Material: Mild Carbon, 304/316 stainless steel, Aluminium Dimension: Width X Span (length of the bearing bar) Bearing Type: Flat or Serrated Bearing Bar (Depth X Thickness) Spacing of the bearing bars Cross Bar Diameter & style (squre twisted or round bar) Cross Bar Pitch With End bands or Not Finish: galvanized, powder or PVDF  QUANTITY (very important for the cost) If need C.F.R offer, just let us the Destination Sea Port.
